AGI Airlanco Cyclones operate without any filter media to clean or replace and are custom-made for their intended applications. We manufacture Cyclones in carbon or stainless steel with round or square inlets and supply a variety of ancillary components, such as duct work, fans, airlocks and other equipment to provide complete integrated systems.
Key Features
Convenient clean air orientation
Rotatable draw-thru can be positioned for convenient clean air orientation.
Optimized cyclonic action
Involute inlet runs 180º around the Cyclone to optimize cyclonic action inside the unit, so that dust particles are forced against the outside wall where inertia and gravity can separate them from the airstream.
Inner riser tube
Directs the ascending secondary vortex to the draw-thru during the final phase of particle separation.
Easy assembly
Flanged construction and lifting lugs facilitate on-site assembly.
Advanced hopper design
Hopper cone features an 8" diameter bolted inspection door. Standard hopper slope is 75º to ensure proper particle flow. If the diameter of the discharge is nonstandard, the hopper height will change to maintain the slope.
