Chain Conveyors

Small to large processing applications with minimum product degradation.

Capacities to 10,000 BPH. Galvanized construction. Flanged bearings. UHMW seals. Screw-type chain tensioning take-up. UHMW return rollers. 3/8" UHMW flighting. Bolt-together construction.
For unloading bucket elevators. Swivel ring arrangement at the discharge provides a secure pivot point. Flex angle connection insures a level hopper in any position. Electric drive operation.
Up to 8,000 BPH (216 TPH). Ultra High Molecular Weight (UHMW) 3/8” thick paddles with metal reinforcement plate. Available with either 10 horsepower (7.5 kw) electric or hydraulic drive with flow control valve and minimum 22 gal/min (83 Vmin) at 2000 PSI (13,790 kPA).
Impressive 10,000, 15,000 and 20,000 BPH capacity.Unload both trailer hoppers at the same time. Equals the capacity of 12” double run grain pump, low profile chain conveyor and Mass-Ter Mover chain conveyor.
10,000 BPH Capacity. Electric Drive with Dodge Gear Reducer. 3/8” Thick UHMW Paddles. Shallow Installation to prevent water table issues. 9 ¼” deep using Commercial Drive Over Option less the ramps.
To transfer or extract granulated or powdered products along a straight horizontal or sloping trajectory. Transport products over long distances at very high flow rates without damage. Low energy consumption.
Durable, dependable and efficient handling capacities for a wide variety of materials with minimum product degradation. Handles from 9,000 to 28,000 bu.
Heavy-Duty Conveyor sides and bottoms are equipped with 3/8" plate A.R. steel liners for extended life. 18" tall side liners are standard construction.
Layco's Flat Wire Chain Conveyor is available in 12", 18", and 24" widths. Units are designed to be portable or stationary and as blender loadout conveyors.

Capacity: Up to 100M.T.P.H. at 45% conveyor loading. Direct coupled gearbox, chain and sprocket. "V" belt drive systems are available. Heavy duty construction, mild steel or stainless steel fabrication.
Capacities up to 200M.T.P.H. Heavy duty totally enclosed take up units ensure that the chain stays tight. Direct coupled gearbox, chain and sprocket , “V" belt drive systems are available.
Capacity up to 300M.T.P.H. No carryover of free flowing dry product when used to fill multiple bin systems and when operated in the ultra clean mode.
Capacities up to 150M.T.P.H. at 95% conveyor loading. Heavy-duty totally enclosed take up units ensure chain stays tight. Heavy duty construction, mild steel or stainless steel fabrication.
Capacities up to 500M.T.P.H. Heavy-duty, totally enclosed take up units ensure that the chain stays tight. Direct coupled gearbox, chain, and sprocket, “V" belt drive systems available.
