Standard Leg Tower Standard Leg Tower


Standard Leg Tower and Support Tower Features:

  • Completely free-standing with no guy wires to clutter your facility
  • Prefabricated bolt-together modular design for economical shipments. Four men with a crane can assemble an 80-foot tower in about one day.
  • Towers are strength-staged for area wind loads to 90 mph or above; tower reactions available upon request
  • Velvet gray polyester powdercoat finish standard; optional galvanized and custom colors available at additional cost
  • Tubular steel construction
  • 5′, 10′ and 20′ lengths
  • Interior cross bracing for support towers
  • Includes all hardware necessary to assemble sections

Stairs

Brownie stair systems offer a unique combination of high quality, personal safety features and cost effectiveness.

  • Safety grips and landings
  • Heavy-duty design to resist deflection
  • Stair units designed to rest on landing for positive location and easy installation
  • Spiral stair wind upward either counterclockwise or clockwise
  • Switchback stair system ascends one face of tower
  • Top landing allows access to service platforms
  • 42″ high handrails
  • Tower-side walkways available

Standard Sizes

  • 4-column 8′ x 8′, 10′ x 10′, 12′ x 12′, 14′ x 14′, 16′ x 16′, 20′ x 20′ or a combination of these sizes
  • 6- or 9-column towers also available

Available Options

  • Access braces allow easy access through the side of the tower in your choice of configurations: Single, Double or Z
  • Internal and top platforms
  • Catwalk-to-tower connection packages
  • Catwalk support and spreader beams
  • Lift beams (2000 lb. capacity)
  • U-lugs for ease of attaching tower to elevator leg
