We are dedicated to extending the life of your auger by adding features that will keep it running smoothly for years to come, including a solid tube drive guard that completely encloses the driveline and protects it from the elements. We have also reinforced our auger flighting with an extra layer of steel at critical wear points and use high quality powder coat paint to keep your auger looking new for longer.
Key Features
Winch for any occasion
Complete with an automatic brake, the hand winch is sized and geared to match each specific auger - giving you the power to raise and lower your auger manually
Proper alignment at all times
The WRX Series uses one-bolt flight connections to ensure the flighting maintains proper alignment for smooth operation. The 8" models feature a round flighting connection and the 10" models use a square connection
Sleek design
This completely enclosed driveline offers a cleaner look and better protection from the elements. This helps keep your driveline intact for longer, preventing costly repairs. Wood Bearings can still be replaced with split bearings
Wear Edge Technology™
Wear Edge Technology™ extends the life of your flighting, providing an extra layer of steel welded to critical wear points. As a result, flighting lasts longer and needs to be replaced less often – saving you time and money
Rigid undercarriage
Undercarriages of heavy steel tubing are designed for each specific auger length for better balance and stability. Upper lift arms sit back from the axle and quickly tuck away for excellent bin eave clearance. Wide axles provide added stability. High-speed wheels with cast iron hubs and tapered roller bearings come standard
Maintenance-free
Our gearboxes have forged steel gears with tapered roller bearings running in oil for years of dependable service
Specifications
WRX8
Tubing gauge
14 GA
Tube connectors
Heavy-duty 3/16" Angle Flange
Main flighting
7" OD x 10 GA Stretched + Welded
Flighting shaft
High Strength 1.66" OD x 11 GA Tubing
Driveshaft
1-¼" OD x 11 GA Tubing
Track
High Yield 11 GA Roll Formed
Capacity - Dry wheat or corn, auger ½ raised
Up to 3,000 BPH
Hubs & wheels
4 Bolt Agricultural Type Hubs, 15" Wheel
WRX10
Tubing gauge
12 GA
Tube connectors
Heavy-duty 3/16" Angle Flange
Main flighting
9" OD x 7 GA Stretched + Welded
Intake flighting
10 GA Welded with Wear Edge Technology™ Lower Pitch for High Capacity
Flighting shaft
High Strength 2" OD x 11 GA Tubing
Driveshaft
1-¼" OD x 11 GA Tubing
Capacity - Dry wheat or corn, auger ½ raised
Up to 4,800 BPH
Hubs & wheels
4 Bolt Agricultural Type Hubs, 15" Wheel
