AGI Batco Belt Conveyors and equipment are built tough to perform, yet designed and engineered for gentle handling of delicate crops, seeds, and commodities.
AGI Batco Belt Conveyors include
- Weather guards are standard on all Batco conveyors
- Maximum service height at 30 degrees
- 2-ply chevron with nylon slider back for proper traction
- Plastic hood and collapsible canvas hoppers to provide cushioning for fragile materials
Key Features
Mechanical swing
The PTO-driven mechanical swing runs at high capacity using a smaller tractor without the need of constant hydraulic flow.
New hopper design & seals
• The bigger hopper gives grain more time to take up speed, unloading trucks faster with smoother, consistent flow.
• Smaller seals exposes more moving belt, increasing capacity while keeping a tight seal.
• Smaller seals exposes more moving belt, increasing capacity while keeping a tight seal.
Overhauled scissor frame
Reinforced scissor frame built to handle tough conditions and the increased capacity.
Reinforced trussing
Run longer conveyors with confidence and long-term durability.
Direct X™ Belt with Edge Seal
Ensures a tight seal between the flashing and the belt without impeding grain flow.
Drive Options
Pinch S-Drive (55' - 100')
- Gas
- Electric
- PTO (side or front)
Top Drive (35')
- Hydraulic
- Electric
Pinch Top Drive (40' - 45')
- Hydraulic
- Electric
Specifications
Capacity
Capacity rated up to 6,000 BPH
length
Available in lengths from 35' to 100'
Diameter
10"
Tube
14 GA
Tube
12 GA tube for the first 30' on 55' to 100' models
